Buy Direct Mi-T-M AGW-SV14-30M 14 HP Vanguard Engine Driven Air Compressor, Generator and Welder Combination 30 Gallon Tank Mount

Product Description

Mi-T-M AGW-SV14-30M 14 HP Vanguard Engine Driven Air Compressor, Generator and Welder Combination 30 Gallon Tank Mount-Recoil Start

A great addition to any work truck. Mi-T-M puts together a two stage air compressor, 5000 Watt Generator and a 170A Max Welder so you are ready for a variety of jobs.

AGW-SV14-30M Features:

• Compressor Pump:
• Splash lubricated
• Stainless-steel braided discharge hose
• Large canister intake filter
• Oil level sight indicator
• Generator:
• Brush-type 2 pole 120V/240V alternator
• Total harmonic distortion (THD) less than 6%
• 100% copper windings
• Welder:
• Amperage selection switch, 170A maximum
• Frame:
• Powder coated ASME coded receiver tanks
• 16-gauge powder coated belt guard
• Components:
• Regulator and two gauges for tank and outlet pressure
• Manual drain valves for proper maintenance
• 161⁄2-inch fly wheel

AGW-SV14-30M Specs:

• 14 HP Vanguard Gasoline Engine Electric Start
• 1.53 Gallon Fuel Tank
• Two Stage Cast Iron Air Compressor Pump
• 16.4 CFM @ 90 psi
• 15.7 CFM @ 175 psi
• 175 psi Max Pressure
• 150 psi Max Regulator
• 5000 Watts Max AC Output Generator
• 4500 Watts Rated AC Output
• Alternator Wattage: Cont. On Load @ 90 psi (3000 Watts)
• Alternator Wattage: Cont. On Load @ 175 psi (2500 Watts)
• 60Hz/120V/240V
• Max Amps: 41.5 (120V) 20.8 (240V) – Offload
• Cont. Amps: 37.5 (120V), 18.8 (240) – Offload
• Receptacles: 2 – 120V, 20A GFCI Duplex, 1 – 120V/240V, 20A Twist Lock
• Welder: 150A @ 100% Duty Cycle (10 Minute Run Time)
• Welder: DC Voltage 50-170A Working Range

Free Standard Shipping (Commercial Delivery with Loading Dock or Fork Lift, Lower 48 States)
