Authentic Schulz SRP 4015 R Dynamic 15 HP Rotary Screw Air Compressor – 460 Volt

Product Description

Schulz SRP 4015 R Dynamic 15 HP Rotary Screw Air Compressor – 460 Volt

SRP 4015 R Features and Specs:

• 15 HP
• 460 Volt
• 51 CFM
• 125 psi Unload Pressure
• 69 dBa
• 3/4″ Outlet
• Tank 120 Gallons
• TEFC, IP55, degree of protection electric motors
• Automatic starters with phase and sequence failure detection
• Lubricated air-end
• Low maintenance costs
• Low oil consumption
• Coolers are on the top of the machine, improves heat recovery at customer’s facilities
• Modern design products
• High efficiency electric motors
• Thermostatic valve for working temperature control
• 24V Command panel.

AIR END
Components and Features

1. Rotors: Exclusive combination of rotors (male and female) that allow for high efficiency in the compression process and greater
efficiency in the production of compressed air. Manufactured with the highest available technology in the market, it guarantees
components of excellent quality.

2. Casings: Manufactured by qualified foundry and machining processes with the latest generation of dimensional analysis
resources, guaranteeing a greater precision in manufacture.

3. Bearings: Developed to support radial and axial loads to maximize the useful life of the product.
